技術分類Technical?Classification

項目規格Item

參數Parameter

電氣性能Electrical?Properties

供電電壓Input?voltage

DC24V

最大功耗Max.power?consumption

18W/20W

光學性能Optical?Properties

光源組成LED?composition

60顆/108顆/180顆/216顆LED

60pcs/108pcs/180pcs/216pcs?LED

顯示像素Pixels

1像素/米?1pixels/meter

光色LED?color

RGB/白光/黃光/藍光

GUB/White/Yellow/Bule

光束角Beam?angle

30°?特殊45°，60°，90°

30°/45°/60°/90°?are?available

光通維持率Luminous?maintenance?rate

50000?hour（@70%）

控制方式Control?Mode

控制接口Interface

DMX512

控制系統Control?System

中鳴科技Easyplay5.0

結構性能Structure

尺寸(長x寬x高)?Dimension?(L*W*H)

1000x43x73mm

重量Weight

1.3?Kg

燈體材料Material

鋁型材

Aluminium?housing

工作溫度Work?temperature

-20℃～50℃

工作濕度Work?humidity

0～90%

儲存溫度?Storage?temperature

-40℃～10℃

使用環境Work?Environment

干燥/潮濕dry/humid

安全性能Safety

防護等級?

Protction?Rating

IP66

供電方式

Input?Voltage

發光顏色LED?Color

產品編號Model

DC24V

RGB?PH5?216顆?20W

RGB?PH5?216pcs?20W

JZ07-121601-011

白光?PH5?180顆?18W

White?PH5?180pcs?18W

JZ07-118003-011

黃光?PH5?180顆?18W

Yellow?PH5?180pcs?18W

JZ07-118002-011

藍光?PH5?180顆?18W

Blue?PH5?180pcs?18W

JZ07-110801-011

白光?食人魚?60顆?18W

White?Piranha?LED?60pcs?18W

JZ07-206003-011

黃光??食人魚?60顆?18W

Yellow?Piranha?LED?60pcs?18W

JZ07-206001-011

藍光??食人魚?60顆?18W

Blue??Piranha?LED?60pcs?18W

JZ07-206002-011
