- Functional Description
- Specifications
- Applications
技術分類Technical?Classification | 項目規格Item | 參數Parameter |
電氣性能Electrical?Properties | 供電電壓Input?voltage | DC24V |
最大功耗Max.power?consumption | 3.6W | |
光學性能Optical?Properties | 光源組成LED?composition | 3顆LED? 3?pcs?of???LED?lamps |
光色LED?Color | 紅色/綠色/藍色/黃色/白色/RGB?Red/Green/Blue/Yellow/White/RGB | |
光通量 luminous?flux | 150?lm | |
光束角?Beam?Angle | 30°/45°/60° | |
亮度等級Brightness?Grade | 每種顏色256?級?256?grade?per?color | |
光通維持率luminous?maintenance?rate | 35000?hour@70% | |
控制方式Control?Mode | 控制接口Interface | DMX512 |
控制系統Control?System | 中鳴科技Easyplay5.0?(Joinmax) | |
結構性能Structure | 尺寸(長x寬x高)?Dimension?(L*W*H) | ?99XH120（mm） |
重量Weight | 850g | |
燈體材料Material | 透明抗UV的鋼化玻璃面蓋，不銹鋼絲防護面罩，壓鑄鋁燈體，陽極氧化表面處理。 Transparent?anti-UV?tempered?glass,stainless?steel?protective?shade?and?die-casting?aluminum?body? | |
表面顏色Surface?Color | 銀色?Silver | |
燈具連接Connection | 公母接頭?Male?and?female?connectors | |
防護等級Protection?Rating | IP68 | |
工作溫度Work?Temperature | -20℃～40℃ | |
使用環境Work?Environment | -20℃～40℃ |
技術分類Technical?Classification | 項目規格Item | 參數Parameter |
電氣性能Electrical?Properties | 供電電壓Input?voltage | DC24V |
最大功耗Max.power?consumption | 3.6W | |
光學性能Optical?Properties | 光源組成LED?composition | 3顆LED? 3?pcs?of???LED?lamps |
光色LED?Color | 紅色/綠色/藍色/黃色/白色/RGB?Red/Green/Blue/Yellow/White/RGB | |
光通量 luminous?flux | 150?lm | |
光束角?Beam?Angle | 30°/45°/60° | |
亮度等級Brightness?Grade | 每種顏色256?級?256?grade?per?color | |
光通維持率luminous?maintenance?rate | 35000?hour@70% | |
控制方式Control?Mode | 控制接口Interface | DMX512 |
控制系統Control?System | 中鳴科技Easyplay5.0?(Joinmax) | |
結構性能Structure | 尺寸(長x寬x高)?Dimension?(L*W*H) | ?99XH120（mm） |
重量Weight | 850g | |
燈體材料Material | 透明抗UV的鋼化玻璃面蓋，不銹鋼絲防護面罩，壓鑄鋁燈體，陽極氧化表面處理。 Transparent?anti-UV?tempered?glass,stainless?steel?protective?shade?and?die-casting?aluminum?body? | |
表面顏色Surface?Color | 銀色?Silver | |
燈具連接Connection | 公母接頭?Male?and?female?connectors | |
防護等級Protection?Rating | IP68 | |
工作溫度Work?Temperature | -20℃～40℃ | |
使用環境Work?Environment | -20℃～40℃ |
-
